SATO CL4NX Plus - LAN Interface

749
Basic Specifications
Power Supply BUS Power through cable
Pin Assignments
Pin No. Description
1 VBus
2 -Data
3 +Data
4 GND
Cable Specifications
Cable Connector USB Type B connector
Cable Length 5 m (16.4 feet) or less
• Specifications are subject to change without notice.
LAN Interface
Basic Specifications
Connector RJ-45 Receptacle
Protocol
• Status3
• Status4
• Status5
IP Address
• IPv4
• IPv6
Subnet Mask / Prefix Length
• IPv4
• IPv6
Gateway Address
• IPv4
