SATO CL4NX Plus User Manual

71
Overview of the Startup Guide
When you power on the product for the first time after purchase, the display shows the startup guide.
The startup guide is a function to help you through the initial product settings, such as setting date and
time, and loading the ribbon and media.
You can cancel the startup guide and perform the configuration later from the menu.
• If you have installed the optional RTC (Real Time Clock) kit, the time zone, date and
time setting screens appear.
The startup guide lets you configure the product by the following flow:
1. Startup Screen
2. Language Selection
Select the display language.
3. Region Setting with Optional RTC Kit
Set the region (time zone).

SATO CL4NX Plus Specifications

General

Display type	LCD
Product color	Black
Built-in display	Yes
Display diagonal	3.5 \
Type	POS printer
Color	No
Print speed	14 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	305 x 305 DPI
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Maximum media length	600 mm
Maximum roll diameter	254 mm
Supported paper width	39.5 - 128 mm
Maximum printing width	128 mm
Printing media thickness	0.06 - 0.268 µm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Wi-Fi	-
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0+HS
Standard interfaces	Bluetooth, Ethernet, RS-232C, Serial, USB 2.0
Serial interface type	RS-232C
USB 2.0 ports quantity	3
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	271 mm
Width	457 mm
Height	321 mm
Weight	15100 g
