629
8.
Press the button to change to Offline mode.
9. Power the product off, and then on again.
When the product is powered on, the barcode checker is also powered on automatically.
When the barcode checker is powered on, it emits a laser light. Be sure to keep the
laser away from your eyes.
When using GFS4170, it keeps emitting a laser light while the product is powered on.
To turn off the laser light, power off the product.
Once the connection between the product and the barcode checker is complete, the barcode
checker icon appears on the status bar of the display.
Do a test read with the barcode checker to confirm that it functions correctly.
If the product cannot detect the barcode checker, check if the operational settings of
the barcode check are appropriate.
Doing a Test Read with the Barcode Checker
Prepare a label on which the barcode data you use is printed by this product.
After performing operational settings of the barcode checker and then connecting it to the product,
perform a test read from the product's [Settings] menu to confirm that the barcode checker functions
correctly.
1.
After connecting the barcode checker, press the power button on the operator
panel until the LED lights up in blue to power on the product.
When the product is powered on, the barcode checker is also powered on automatically.

Table of Contents

Other manuals for SATO CL4NX Plus

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the SATO CL4NX Plus and is the answer not in the manual?

SATO CL4NX Plus Specifications

General IconGeneral
Display typeLCD
Product colorBlack
Built-in displayYes
Display diagonal3.5 \
TypePOS printer
ColorNo
Print speed14 ips
Print technologyDirect thermal / Thermal transfer
Maximum resolution305 x 305 DPI
AC input voltage100 - 240 V
Power source typeAC
AC input frequency50 - 60 Hz
Maximum media length600 mm
Maximum roll diameter254 mm
Supported paper width39.5 - 128 mm
Maximum printing width128 mm
Printing media thickness0.06 - 0.268 µm
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)30 - 90 %
Operating relative humidity (H-H)30 - 80 %
Wi-Fi-
USB connectorUSB Type-A / USB Type-B
Bluetooth version3.0+HS
Standard interfacesBluetooth, Ethernet, RS-232C, Serial, USB 2.0
Serial interface typeRS-232C
USB 2.0 ports quantity3
Connectivity technologyWired & Wireless
Ethernet LAN (RJ-45) ports1
Weight and Dimensions IconWeight and Dimensions
Depth271 mm
Width457 mm
Height321 mm
Weight15100 g
