SATO CL4NX Plus User Manual

NFC Interface
750
Basic Specifications
• IPv6
Cable Specifications
Cable 10BASE-T/100BASE-TX Category 5
Cable Length 100 m (328 feet) or less
Software Specifications
Supported Protocol TCP/IP
Network Layer IP, ICMP
Session Layer TCP
Application Layer LPD, FTP, DHCP, HTTP/HTTPS, SNMP, NTP
• Specifications are subject to change without notice.
Bluetooth Interface
This interface complies with the Bluetooth3.0+EDR standard.
Basic Specifications
Signal Level Class 2
Communication Distance 10 m (32.8 feet)
Profile Serial Port Profile
Security Level None, level 2-1, 2-2, level 3, level 4
PIN Code 1 to 16 characters consisting of ASCII code (20H, 21H, 23H to 7EH)
Disconnect Timeout (LMP
Layer)
60 seconds
• Specifications are subject to change without notice.
NFC Interface
This interface complies with the NFC Forum Type 2 Tag.

SATO CL4NX Plus Specifications

General

Display type	LCD
Product color	Black
Built-in display	Yes
Display diagonal	3.5 \
Type	POS printer
Color	No
Print speed	14 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	305 x 305 DPI
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Maximum media length	600 mm
Maximum roll diameter	254 mm
Supported paper width	39.5 - 128 mm
Maximum printing width	128 mm
Printing media thickness	0.06 - 0.268 µm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Wi-Fi	-
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0+HS
Standard interfaces	Bluetooth, Ethernet, RS-232C, Serial, USB 2.0
Serial interface type	RS-232C
USB 2.0 ports quantity	3
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	271 mm
Width	457 mm
Height	321 mm
Weight	15100 g
