About the Base Reference Point
598
Adjusting the Base Reference Point
About the Base Reference Point
The base reference point is the point at which one determines the print position and stop/cut/
dispensing position.
The base reference point differs depending on the operation mode or media sensor you use.
Continuous Mode/Tear-off Mode
I-mark Label Gap Label
(1) Feed direction
(2) Print and stop position
(1) Feed direction
(2) Print and stop position
Cutter Mode
I-mark Label Gap Label
(1) Feed direction
(2) Print and cut position
(1) Feed direction
(2) Cut position
(3) Print position

SATO CL4NX Plus Specifications

General

Display type	LCD
Product color	Black
Built-in display	Yes
Display diagonal	3.5 \
Type	POS printer
Color	No
Print speed	14 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	305 x 305 DPI
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Maximum media length	600 mm
Maximum roll diameter	254 mm
Supported paper width	39.5 - 128 mm
Maximum printing width	128 mm
Printing media thickness	0.06 - 0.268 µm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Wi-Fi	-
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0+HS
Standard interfaces	Bluetooth, Ethernet, RS-232C, Serial, USB 2.0
Serial interface type	RS-232C
USB 2.0 ports quantity	3
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	271 mm
Width	457 mm
Height	321 mm
Weight	15100 g
