SATO CL4NX Plus User Manual

Built-in Functions
764
Built-in Functions
Item CL4NX Plus
Built-in Functions
• Status return
• Graphic
• Sequential number
• Form overlay
• Character modification
• Black/white inversion
• Ruled line
• Dump list
• Format registration
• Outline font
• Outline modification
• Zero slash switching
• Guidance video
• LCD display in 31 languages
• Cleaning notification
• Calendar (Optional)
• Barcode check (Optional)
• Password lock
• Logo, font download
• LCD turns off
• Standby
• Total print count indication
• Reprint
• Power on in Online mode
• Feed after error
• Feed at power on
• Command error indication
• Non-standard mode
• Priority settings
Self-diagnosis
Functions
• Broken head element check
• Head open detection
• Media size check
• Paper end detection
• Label near end detection

SATO CL4NX Plus Specifications

General

Display type	LCD
Product color	Black
Built-in display	Yes
Display diagonal	3.5 \
Type	POS printer
Color	No
Print speed	14 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	305 x 305 DPI
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Maximum media length	600 mm
Maximum roll diameter	254 mm
Supported paper width	39.5 - 128 mm
Maximum printing width	128 mm
Printing media thickness	0.06 - 0.268 µm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Wi-Fi	-
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0+HS
Standard interfaces	Bluetooth, Ethernet, RS-232C, Serial, USB 2.0
Serial interface type	RS-232C
USB 2.0 ports quantity	3
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	271 mm
Width	457 mm
Height	321 mm
Weight	15100 g
