SATO CL4NX Plus User Manual

83
Media Sensor Type Setting
Set the sensor type for detecting the media.
1.
Select the media sensor type using the / buttons.
[None]
Disable the media sensor.
[Gap]
Select this option when using gap type media. Use the transmissive type sensor.
[I-Mark]
Select this option when using I-mark type media. Use the reflective type sensor.
• The available options will vary depending on the [Print Mode] set on the product. The
initial value of [Print Mode] differs depending on the options installed on the product.
◦ If [Print Mode] is set to [Tear-Off], [Dispenser], or [Cut & Print], only [Gap] and [I-Mark]
will be available.
◦ If [Print Mode] is set to [Linerless], only [None] and [I-Mark] will be available.
2.
Press the button or button to confirm.

SATO CL4NX Plus Specifications

General

Display type	LCD
Product color	Black
Built-in display	Yes
Display diagonal	3.5 \
Type	POS printer
Color	No
Print speed	14 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	305 x 305 DPI
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Maximum media length	600 mm
Maximum roll diameter	254 mm
Supported paper width	39.5 - 128 mm
Maximum printing width	128 mm
Printing media thickness	0.06 - 0.268 µm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Wi-Fi	-
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0+HS
Standard interfaces	Bluetooth, Ethernet, RS-232C, Serial, USB 2.0
Serial interface type	RS-232C
USB 2.0 ports quantity	3
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	271 mm
Width	457 mm
Height	321 mm
Weight	15100 g
