SATO CL4NX Plus User Manual

653
List of Initial Values
[Printing] Menu
The initial value refers to the setting value of the product when it was shipped from the factory. If you
reset the product, the setting values of the product will change back to the factory default values. The
table below shows the initial value of each setting item and type of reset that changes the value back
to the initial value.
• Normally, it is not necessary to perform the initialization. Doing an initialization removes
all the product's settings that the customer changed.
Setting Item Initial Value User
Reset
Factory
Reset
[Label Length]
203 dpi
20000 dots
305 dpi
18000 dots
609 dpi
9600 dots
Yes Yes
[Label Width]
203 dpi
832 dots
305 dpi
1248 dots
609 dpi
2496 dots
Yes Yes
[Auto Measure] Disabled Yes Yes
[Printing Mode] Use Ribbon Yes Yes
[Ribbon Near End] Enabled Yes Yes
[Speed]
203 dpi
6 ips
305 dpi
6 ips
609 dpi
4 ips
Yes Yes

SATO CL4NX Plus Specifications

General

Display type	LCD
Product color	Black
Built-in display	Yes
Display diagonal	3.5 \
Type	POS printer
Color	No
Print speed	14 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	305 x 305 DPI
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Maximum media length	600 mm
Maximum roll diameter	254 mm
Supported paper width	39.5 - 128 mm
Maximum printing width	128 mm
Printing media thickness	0.06 - 0.268 µm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Wi-Fi	-
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0+HS
Standard interfaces	Bluetooth, Ethernet, RS-232C, Serial, USB 2.0
Serial interface type	RS-232C
USB 2.0 ports quantity	3
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	271 mm
Width	457 mm
Height	321 mm
Weight	15100 g
