SATO CL4NX Plus User Manual

[Printing] Menu
654
Setting Item Initial Value User
Reset
Factory
Reset
Linerless mode
4 ips
[Sensor Type] Gap
None (When [Print Mode] is
[Linerless])
Yes Yes
[Micro Label Print Mode]
[Micro Label Print Mode] Disable Yes Yes
[Auto Label Length Detection] Enable Yes Yes
[Label Length Averaging Count] 3 Yes Yes
[Label Length]
203 dpi
320 dots
305 dpi
480 dots
609 dpi
960 dots
Yes Yes
[Auto-mode] Enabled Yes Yes
[Print Mode] Tear-Off (If no option is installed)
Cutter (If cutter unit is installed)
Dispenser (If dispenser unit is
installed)
Linerless (If linerless cutter kit is
installed)
Yes Yes
[Backfeed] Before (If [Print Mode] is set to
[Tear-Off] or [Linerless])
After (If [Print Mode] is set to
[Dispenser], [Cutter] or [Cut &
Print])
None (If [Print Mode] is set to
[Continuous])
Yes Yes
[Eject Cut] Off Yes Yes
[Darkness Range] A Yes Yes
[Darkness] 5 Yes Yes
[Imaging]

SATO CL4NX Plus Specifications

General

Display type	LCD
Product color	Black
Built-in display	Yes
Display diagonal	3.5 \
Type	POS printer
Color	No
Print speed	14 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	305 x 305 DPI
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Maximum media length	600 mm
Maximum roll diameter	254 mm
Supported paper width	39.5 - 128 mm
Maximum printing width	128 mm
Printing media thickness	0.06 - 0.268 µm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Wi-Fi	-
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0+HS
Standard interfaces	Bluetooth, Ethernet, RS-232C, Serial, USB 2.0
Serial interface type	RS-232C
USB 2.0 ports quantity	3
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	271 mm
Width	457 mm
Height	321 mm
Weight	15100 g
