SATO CL4NX Plus User Manual

[Regional]
440
[Regional]
Set the display language, time zone, calendar (option) and unit.
The setting items are as follows:
Messages
Set the display language of the LCD.
USB Keyboard
Set the language for the USB keyboard connected to the product.
Locale
Set the locale to be used in AEP (Application Enabled Printing) mode.
Unit
Set the unit of length for indication.
Time
Set the time.
• You can set the time only if you have installed the optional RTC kit.
Date
Set the date.
• You can set the date only if you have installed the optional RTC kit.
Time Zone
Set the time zone.
Display Language Icon
Set whether to display the [Language] icon on the top screen of the [Settings] menu.

SATO CL4NX Plus Specifications

General

Display type	LCD
Product color	Black
Built-in display	Yes
Display diagonal	3.5 \
Type	POS printer
Color	No
Print speed	14 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	305 x 305 DPI
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Maximum media length	600 mm
Maximum roll diameter	254 mm
Supported paper width	39.5 - 128 mm
Maximum printing width	128 mm
Printing media thickness	0.06 - 0.268 µm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Wi-Fi	-
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0+HS
Standard interfaces	Bluetooth, Ethernet, RS-232C, Serial, USB 2.0
Serial interface type	RS-232C
USB 2.0 ports quantity	3
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	271 mm
Width	457 mm
Height	321 mm
Weight	15100 g
