SATO CL4NX Plus - Page 473

473
Resolution CL4NX Plus
203 dpi
(1 dot = 0.125 mm (0.0049"))
320 to 832 dots
305 dpi
(1 dot = 0.083 mm (0.0033"))
480 to 1248 dots
609 dpi
(1 dot = 0.042 mm (0.0017"))
960 to 2496 dots
Label Length
Set the length of one piece of the media used for the head check print.
The setting range varies depending on the print resolution of the product.
The setting range is as follows:
Resolution CL4NX Plus
203 dpi
(1 dot = 0.125 mm (0.0049"))
40 to 240 dots
305 dpi
(1 dot = 0.083 mm (0.0033"))
60 to 360 dots
609 dpi
(1 dot = 0.042 mm (0.0017"))
120 to 720 dots
Pitch
Set the print position in the vertical direction.
The setting range varies depending on the print resolution of the product.
The setting range is as follows:
Resolution CL4NX Plus
203 dpi
(1 dot = 0.125 mm (0.0049"))
-30 to 0 to 30 dots
305 dpi
(1 dot = 0.083 mm (0.0033"))
-45 to 0 to 45 dots
609 dpi
(1 dot = 0.042 mm (0.0017"))
-90 to 0 to 90 dots
When you decrease the setting value, the print position moves in the feed direction (toward the
front part of the media).
When you increase the setting value, the print position moves opposite the feed direction (toward
the end part of the media).
