[Test Print]
472
Resolution CL4NX Plus
(1 dot = 0.042 mm (0.0017"))
When you decrease the setting value, the stop position moves in the feed direction (toward the
front part of the media).
When you increase the setting value, the stop position moves opposite the feed direction (toward
the end part of the media).
Darkness Adjust
Fine tune the print darkness of the test print.
0 is the lightest and 99 is the darkest.
• The value of [Label Length], [Pitch], [Offset] and [Darkness Adjust] set in the [Paper
Sensor] menu will be reflected to the same item settings in the [Factory] menu,
[Configure List] menu, [Configure QR] menu and [Head Check] menu.
[Head Check]
Perform the head check print.
1. Check and set the items as listed on the [Head Check] menu.
2.
Press the button to start the head check print. Press the button again to
pause the print.
To stop the head check print, first pause the print and then press the button.
The setting items are as follows:
Label Width
Set the media width used for the head check print.
The setting range varies depending on the print resolution of the product.
The setting range is as follows:
