SATO CL4NX Plus User Manual

Wireless LAN Interface
762
Basic Specifications
Protocol Status3, Status4, Status5
IP Address
• IPv4
• IPv6
Subnet Mask / Prefix Length
• IPv4
• IPv6
Gateway Address
• IPv4
• IPv6
Data Transfer Method
802.11a
Max 54 Mbps
802.11n
Max 135 Mbps
802.11b
Max 11 Mbps
802.11g
Max 54 Mbps
• These are the logical values based on the wireless
LAN specifications and are not the actual data transfer
speeds.
Frequency Band
• 2.4 GHz (2.412 to 2.472 GHz)
• 5 GHz (5.180 to 5.825 GHz)
Communication Channel The number of channels you can set varies depending on the
region where you use the product.
SSID Any alphanumeric character (Maximum 32)
Authentication
• Open System
• Shared Key
• WPA/WPA2
• Perform the RADIUS server authentication using 802.1x (EAP-
TLS, EAP-LEAP, EAP-TTLS, EAP-PEAP, EAP-FAST protocol)
Encryption
• None
• WEP (64 bits/128 bits)
• TKIP (WPA-PSK, WPA-802.1x)
• AES (WPA2-PSK, WPA2-802.1x)
Communication Mode
• Infrastructure

SATO CL4NX Plus Specifications

General

Display type	LCD
Product color	Black
Built-in display	Yes
Display diagonal	3.5 \
Type	POS printer
Color	No
Print speed	14 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	305 x 305 DPI
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Maximum media length	600 mm
Maximum roll diameter	254 mm
Supported paper width	39.5 - 128 mm
Maximum printing width	128 mm
Printing media thickness	0.06 - 0.268 µm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Wi-Fi	-
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0+HS
Standard interfaces	Bluetooth, Ethernet, RS-232C, Serial, USB 2.0
Serial interface type	RS-232C
USB 2.0 ports quantity	3
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	271 mm
Width	457 mm
Height	321 mm
Weight	15100 g
