Sirona Dental Systems GmbH 4 Operation
Operating Instructions SINIUS / SINIUS CS 4.6 Assistant element
båÖäáëÜ
4.6.3.4
Chair programs S and 0
Chair programs S and 0
The chair programs Mouth rinsing position (S) and Entry/exit position (0)
can be selected on the assistant element:
For details, see"Moving the patient chair via chair programs" [ → 67].
Mouth rinsing position and Entry/exit position programs can also be
programmed from the assistant element side, see "Programming chair
programs and shock positioning" [ → 72].
4.6.3.5
Hash key
Hash key
The
Hash key
on the assistant element can be configured in the Setup
program. The key allows the user to switch the X-ray viewer or the white
screen function on the SIVISION monitor on or off or alternatively to
activate the bell or hash relay, see “Setting function of the Hash key on
assistant element” [ → 162].
The white screen function is available if the treatment center has no X-ray
viewer, but is equipped with a SIVISION monitor, see “Show/hide white
screen key on SIVISION monitor" [ → 161].
➢ Press the
Hash key
.
If the
hash key
is set on the control of X-ray viewer, bell or hash
relay, the LED of the key illuminates when the function is
activated.
If the White screen function is controlled in SIVISION monitor
using the
hash key
, the LED of the
hash key
is not illuminated. It
is lit only when the X-ray viewer is switched on. In addition, the
White screen
key is no longer shown in orange in the
Start
program
.
