Sirona Sinius - Inclining the Headrest

63 22 726 D3561
D3561.201.01.03.02 05.2012
65
Sirona Dental Systems GmbH 4 Operation
Operating Instructions SINIUS / SINIUS CS 4.4 Patient chair
båÖäáëÜ
4.4.5.2
Inclining the headrest
Inclining the headrest
The headrest can be tilted either via motor drive or manually (quick
mechanical adjustment).
Tilting headrest via touchscreen, Start program without instrument functions
Via touchscreen
✔ The Start program without instrument functions or the Manual Chair
Adjustment
program is displayed on the touchscreen.
➢ Touch the
Tilt headrest keys.
Via the 4-way switch
➢ Slide the upper 4-way switch to the left or right.
Via quick mechanical adjustment
1. Hold the headrest securely in place before unlocking it.
2. Press buttons A together.
 The headrest is thus disconnected from the motor drive and can
be tilted manually.
Via the 4-way foot switch
It can be set so that the tilt of the headrest can be adjusted using the 4-
way foot switch at the base of the chair; see"Linking the motor-driven
headrest to the 4-way foot switch".
➢ Actuate the 4-way foot switch to the left or right.
A
A
