Sirona Sinius - Headrest; Motor-Driven Headrest

63 22 726 D3561
D3561.201.01.03.02 05.2012
29
Sirona Dental Systems GmbH 3 Unit description
Operating Instructions SINIUS / SINIUS CS 3.5 Headrest
båÖäáëÜ
3.5
Headrest
Headrest
3.5.1 Motor-driven headrest
Motor-driven headrest
The headrest allows for the following adjustment options:
● Motor-driven extension/retraction to adapt to the patient's stature
● Motor-driven tilting for maxillary/mandibular treatment
● Manual tilting via quick mechanical adjustment
● Shifting/rotation of the head support via the magnetic holder
For details, see "Adjusting the motor-driven headrest" [ → 64].
A Removable head pad with magnetic holder
B Quick mechanical adjustment of headrest tilt
C Upper 4-way switch for headrest functions
D Lower 4-way switch for chair functions
D
C
B
A
