Sirona Dental Systems GmbH 3 Unit description
Operating Instructions SINIUS / SINIUS CS 3.10 Outlet for add-on devices
båÖäáëÜ
3.10
Outlet for add-on devices
Outlet for add -on devices
External medical accessories can be connected to the external device
connection. They must comply with the requirements of the Medical
Device Directive 93/42/EEC.
Additional devices, hydrogen peroxide up to 0.2‰, disinfection system optional
External d evice connection, DVGW with additional devices, disinfection system optional
External d evice connection, inlet connector
NOTICE
If the treatment center is equipped with a disinfection system, additional
devices are exposed to a hydrogen peroxide concentration ((H
2
O
2
) of
0.1‰-0.2‰ at the external device connection.
If the additional devices are not suitable for the specified hydrogen
peroxide concentration, they may be damaged.
➢ Before connecting any additional devices, check to make sure that
they can be exposed to the above hydrogen peroxide concentration.
Contact the manufacturer of the relevant additional device, if
necessary.
➢ Prior to sanitation, additional devices must be unplugged from the
external device connection (water connection), see "Sanitizing the
treatment center" [ → 207].
IMPORTANT
DVGW approval
As the treatment center is designed according to EN 1717/DIN 1988
(DVGW requirements), the connected additional devices also fulfill the
requirements of the above standards when a disinfection system is
integrated, see "Standards and approvals" [ → 22].
IMPORTANT
Self-contained power supply
The inlet connector remains live when the power switch is turned off.
The connected external devices therefore must possess their own
power switch.
However, the air and water connections are switched off.
A Inlet connector with power supply (max. 6 A)
B Fuse for inlet connector (6.3 A slow-blow)
