Sirona Sinius - Moving the Patient Chair to the Mouth Rinsing Position

63 22 726 D3561
68 D3561.201.01.03.02 05.2012
4 Operation Sirona Dental Systems GmbH
4.4 Patient chair Operating Instructions SINIUS / SINIUS CS
Via foot control
✔ All instruments are in place.
➢ Press the right button of the foot control.
Via the assistant element
➢ Press the 0 key on the assistant element briefly (< 2 s).
4.4.7.2
Moving the patient chair to the mouth rinsing position
Moving the patient chair to the mouth rinsing position
The following functions are triggered in the mouth rinsing position:
● The operating light switches off
● The chair moves the patient to an upright position
Via touchscreen
✔ The Start program is displayed on the touchscreen.
➢ Touch the
S key briefly (< 2 s).
Via foot control
✔ All instruments are in place.
➢ Press the left button of the foot control.
Via the assistant element
➢ Press the S key on the assistant element briefly (< 2 s).
S
0
0
S
0
S
