Sirona Dental Systems GmbH 4 Operation
Operating Instructions SINIUS / SINIUS CS 4.6 Assistant element
båÖäáëÜ
You can interrupt the curing cycle immediately by pressing the on/off
button (C).
For care and cleaning, see "Disinfecting and sterilizing the Mini L.E.D.
curing light" [ → 188].
4.6.6.5
Technical Data
Technica l Data
General Technical Data on Mini L.E.D.
Optical specification of Mini L.E.D.
Hazard distance (HD) and exposure
hazard value (EHV) according to IEC
62471
Model: Mini L.E.D.
Weight of handpiece without hose: 105 g
Dimensions: Dia. 23mm x 240mm
Current draw of handpiece: 5 V DC / 0.65 A
Thermal safety: Overheat protection
Wavelength:
Max. intensity:
420 nm – 480 nm
at 450nm
Light power dia. 7.5 mm (standard
version):
1100mW/cm
2
Light power dia. 5.5 mm (available
from Satelec):
2000 mW/cm
2
Light power: 450 mW – 500 mW
Classification acc. to IEC 62471 Risk group 2 with light bar removed
HD EHV
Blue light
Free group
907 mm 20,6
Blue light
Risk group 1
323 mm 2,6
Blue light
Risk group 2
–0,01
Thermal hazard to the
cornea
Free group
–0,97
