Sirona Sinius - 4.2 Control concept of touchscreen

63 22 726 D3561
48 D3561.201.01.03.02 05.2012
4 Operation Sirona Dental Systems GmbH
4.2 Control concept of touchscreen Operating Instructions SINIUS / SINIUS CS
4.2
Control concept of touchscreen
Control concept of to uchscreen
4.2.1 Virtual function keys
Virtual function keys
The touchscreen displays virtual function keys according to the program
selected. Required functions can be triggered either by touching the
function keys with your finger or via cursor with the foot control.
Missing function keys
The adjacent illustration shows the touchscreen of a treatment center as
supplied to the customer and maximally equipped.
Function keys for functions which the treatment center equipment does
not include are not displayed on the touchscreen. Moreover, the
touchscreen user interface can be altered via individual Setup changes,
see "Configuration of the treatment center (Setup)" [ → 157].
In the
Start program this includes function keys for the following
equipment options:
● Motor-driven headrest *
● X-ray viewer
● Endodontic treatment *
Keys marked with * are not displayed in the
Start program with instrument
functions
. Equipment options can still be available, see “Instrument
functions in the Start program" [ → 49].
Furthermore, the screens may vary due to individual Setup settings. The
following configurations may influence the
Start program , see:
● "Preselecting the number of user profiles" [ → 160]
● "Setting the X-ray viewer key to white screen on SIVISION
monitor" [ → 161]
Key background color
General functions are represented by gray keys. If the corresponding
function is switched on or active, the key is displayed orange.
Keys that initiate a program change or lead to sub-screens and settings
screens are displayed blue.
As long as a key remains activated, its active state is marked by a bold
black border.
