5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH
5.3 Instruments and instrument hoses Operating Instructions SINIUS / SINIUS CS
5.3.5 Changing the cotton wool roll on the high-speed
handpiece hose and oil collector
Changing the cotton wool roll on the high-speed handpiece hose and oil collector
Return air containing a small amount of high-speed handpiece oil is
emitted at the unit end of the high-speed handpiece hose. This oil is
collected in a drip container by the cotton wool roll.
SINIUS dentist element
1. Push the drip container down and remove the cotton wool roll.
2. Insert new cotton wool roll and again push the container up.
SINIUS CS dentist element
Cotton wool roll on the high-speed handpiece hose
The instrument connections are located below the instrument holder. The
holder is fixed on the front edge with two internal clamps on the dentist
element.
1. The instruments must be removed from the instrument holder. To do
this, remove all instruments one after the other and allow these to
overhang facing forward.
2. Lift the instrument holder by the front edge until the clamps are
released and the holder can be removed.
3. Push the drip container on the high-speed handpiece hose up and
remove the cotton wool roll.
4. Insert new cotton wool roll and again push the container down.
5. First insert the rear edge of the instrument holder into the groove on
the dentist element. Then push the holder forward and down until it
clicks into place.
6. Place the instruments in their holders. Make sure that the instrument
hoses are located in the guide rolls of the swivel arm.
