Sirona Sinius - Setting the Speed

63 22 726 D3561
D3561.201.01.03.02 05.2012
101
Sirona Dental Systems GmbH 4 Operation
Operating Instructions SINIUS / SINIUS CS 4.5 Dentist element
båÖäáëÜ
4.5.10.2
Setting the speed
Setting the speed
Quick setting keys and function levels can only be accessed in the Start
program without instrument functions
operating mode. In the Start
program with instrument functions
operating mode, the speed must be set
by using the - and + keys, see “Setting speed in the Start program with
instrument functions” (below).
Selecting the speed with the quick setting keys
✔ The Start program without instrument functions operating mode is
selected.
✔ The electric motor is removed.
✔ The Motor screen is displayed on the touchscreen.
➢ Touch one of the quick setting keys in the bottom line key briefly
(< 1 s).
 The quick setting key is highlighted orange. The selected speed
is displayed in the first line in rpm (revolutions per minute).
Electric motor, rpm values of quick setting keys
Selecting intermediate speed values with quick setting keys
✔ The Start program without instrument functions operating mode is
selected.
✔ The electric motor is removed.
✔ The Motor screen is displayed on the touchscreen.
➢ Increasing the speed: Press andhold a quick setting key whose
speed value is greater than or equal to the value displayed in the first
line (> 1 s).
Reducing the speed: Press andhold a quick setting key whose speed
value is less than the value displayed in the first line (> 1 s).
 The selected speed is displayed in the first line in rpm
(revolutions per minute). The quick setting keys are shaded gray
for intermediate values.
IMPORTANT
Rpm values of quick setting keys
The speed of the motor in rpm equals 1,000x the speed value shown on
the key times.
The 0.09 key = 90 rpm (for BL and BL ISO C motors)
The 0.20 key = 200 rpm (for BL ISO S motors)
The 20 key = 20,000 rpm
The 40 key = 40,000 rpm
Please note that the speed of the burr depends on the selected straight
or contra-angle handpiece.
