FRONT DRIVE SHAFT (G10/M13 ENGINES) 4A-5
Installation
Reverse removal procedure for installation noting the following.
• Install wheel side joint to steering knuckle first, and then dif-
ferential side joint to transaxle.
• Tighten each bolt and nut to the specified torque referring to
“Front Drive Shaft Assembly Construction” in this section.
• Fill transaxle oil as follows.
– For M/T model with G10 engine
Refer to “Oil Change” in Section 7A of the Service Manual
mentioned in the FOREWORD of this manual.
– For M/T model with M13 engine
Refer to “Transaxle Oil Change” in Section 7A2.
– For A/T model
Refer to “Fluid Change” in Section 7B1.
• Fill transfer oil referring to “Oil Change” in Section 7D of the
Service Manual mentioned in the FOREWORD of this man-
ual.
• Check toe setting and adjust referring to “Toe Setting” and
“Toe Adjus t m ent ” in Section 3A.
Front Drive Shaft Assembly Inspection
• Check boots for breakage or deterioration.
• Check wheel side joint for rattle or smoothness.
• Check differential side joint for smoothness.
If any abnormality is found, replace.
CAUTION:
• Be careful not to damage oil seals and boots when
installing drive shafts.
• Do not hit joint boot with hammer. Inserting joint only
by hands is allowed.
• Make sure that differential side joint is inserted fully
and its snap ring is seated as it was.
