ENGINE MECHANICAL (M13 ENGINE) 6A2-93
Cylinder head bolt for M10 Tighten 20 N·m (2.0 kg-m, 14.5 lb-ft), 40 N·m (4.0 kg-m, 29.0 lb-ft),
60° and 60° by the specified procedure.
Bearing cap nut Tighten 15 N·m (1.5 kg-m, 11.0 lb-ft), 45° and 45° by the specified
procedure.
Engine mounting bolt for M8 25 2.5 18.0
Engine mounting bolt and nut for M10 55 5.5 40.0
Engine right mounting nut 65 6.5 47.0
Main bearing cap No.1 bolt Tighten 30 N·m (3.0 kg-m, 22.0 lb-ft), 50 N·m (5.0 kg-m, 36.5 lb-ft)
and 60° by the specified procedure.
Main bearing cap No.2 bolt Tighten 25 N·m (2.5 kg-m, 18.0 lb-ft) by the specified procedure.
Sensor plate bolt 11 1.1 8.0
Rear oil seal housing bolt 11 1.1 8.0
Flywheel mounting bolt 70 7.0 51.0
Oil filter adapter bolt 25 2.5 18.0
Clutch housing lower plate bolt 50 5.0 36.5
Timing chain tensioner bolt 25 2.5 18.0
Oil gallery pipe No.1 bolt 30 3.0 21.5
Oil gallery pipe No.2 bolt 11 1.1 8.0
Oil gallery pipe No.3 bolt 11 1.1 8.0
Oil control valve mounting nut 11 1.1 8.0
Water outlet cap bolt 25 2.5 18.0
Intake camshaft sprocket bolt 60 6.0 43.0
Fastening part
Tightening torque
N•m kg-m lb-ft
