7B1-88 AUTOMATIC TRANSAXLE (M13 ENGINE)
E12
6WHT
Input shaft speed sensor
(+)
2 – 3 V
Ignition switch turned ON, engine
stops.
(Reference
waveform
No.1)
While engine running.
(Output signal is waveform. Wave-
form frequency varies depending on
output shaft speed. (16 pulses are
generated par 1 input shaft revolu-
tion.))
7 GRN/RED
Transmission range sen-
sor (“D” range)
8 – 14 V
Ignition switch ON, selector lever at
“R” range
0 – 1 V
Ignition switch ON, selector lever at
other than “R” range
8BUL/YEL
Transmission range sen-
sor (“N” range)
8 – 14 V
Ignition switch ON, selector lever at
“N” range
0 – 1 V
Ignition switch ON, selector lever at
other than “N” range
9 BLU/RED O/D OFF switch
0 – 1 V O/D OFF switch pressed
8 – 14 V O/D OFF switch released
10 ––– –
11 BLU/YEL “O/D OFF” light
0 – 1 V Ignition switch ON (lamp turned ON)
8 – 14 V Ignition switch ON (lamp turned OFF)
12 ––– –
13 ––– –
14 ––– –
15 ––– –
16 BLK
Input shaft speed sensor
(–)
2 – 3 V Ignition switch ON, engine at stop
17 ––– –
18 GRN/BLK
Transmission range sen-
sor (“L” range)
8 – 14 V
Ignition switch ON, selector lever at
“L” range
0 – 1 V
Ignition switch ON, selector lever at
other than “L” range
19 GRN
Transmission range sen-
sor (“2” range)
8 – 14 V
Ignition switch ON, selector lever at
“2” range
0 – 1 V
Ignition switch ON, selector lever at
other than “2” range
20 ORN
Transmission range sen-
sor (“P” range)
8 – 14 V
Ignition switch ON, selector lever at
“P” range
0 – 1 V
Ignition switch ON, selector lever at
other than “P” range
21 ––– –
22 ––– –
23 WHT/RED Data link connector 8 – 14 V Ignition switch ON
24 ––– –
25 YEL
Output shaft speed sen-
sor (VSS)
8 – 14 V Ignition switch ON
0 – 1 V
↑↓
10 – 14 V
(Reference
waveform
No.2)
Vehicle running.
(Sensor signal is pulse. Pulse fre-
quency varies depending on vehicle
speed.)
26 ––– –
Con-
nector
Terminal
number
Wire color Circuit
Normal
Voltage
Condition
