7B1-102 AUTOMATIC TRANSAXLE (M13 ENGINE)
9) Remove TCC solenoid valve (1), shift solenoid valve-A
(No.1) (2), shift solenoid valve-B (No.2) (3) and timing sole-
noid valve (4) by removing bolts.
Inspection
Resistance Check
Shift solenoid valves, Timing solenoid valve and TCC
solenoid valve resistance
Standard: 11 – 15
Ω
at 20°C (68°F)
