FRONT SUSPENSION 3D-9
2) Remove circlip (1).
Special tool
(A): 09900-06108
3) Remove wheel bearing using special tool and hydraulic
press.
Special tool
(A): 09913-75810 (for gasoline engine model)
(A): 09913-85210 (for diesel engine model)
4) Remove wheel bearing outside inner race (1) as shown by
hammering lightly at 3 locations around it so as not to cause
damage to seating part (2) of wheel hub.
Special tool
(C): 09913-61110
(D): 09925-88210
Assembly
1) Face grooved rubber seal side (1) of new wheel bearing
upward as shown and press-fit new wheel bearing into
knuckle using special tools.
Special tool
(A): 09913-75520 (for gasoline engine model)
(A): 09913-75510 (for diesel engine model)
(B): 09951-18210
CAUTION:
• Never reuse wheel bearing.
• When replacing bearing, inner races or outer race, be
sure to replace them with new ones as a set.
