3D-8 FRONT SUSPENSION
9) Remove tie-rod end nut and disconnect tie-rod end (2) from
knuckle (1) with puller.
10) Remove wheel speed sensor (1) from knuckle (if equipped).
11) Remove strut bracket bolts (1) from strut bracket and then
control arm ball stud bolt (2).
12) Remove knuckle (3).
Disassembly
1) Uncaulk and remove dust cover (1).
CAUTION:
• Never reuse tie-rod end nut.
• Reused nut will not be locked securely.
To Next Page
