TPS-1500W Sealed Peltier Recirculator
304 Evolution 200 Series User Guide Thermo Scientific
3. When the desired set temperature is displayed, press Change to return to the main
Normal Mode page.
Parameters Menu
• From the main Normal Mode page, press the Menu button to display the Main Menu
page.
•Use the left (Scroll) button to highlight Parameters and press the center (Select) button
to select it. A list of available parameters appears.
•Use the left (Scroll) button to highlight a parameter.
•Use the center (Select) button to select the highlighted parameter.
•Use the right (Exit) button to return to the Parameters Menu.
Configure Menu
• From the main Normal Mode page, press the Menu button to display the Main Menu
page.
•Use the left (Scroll) button to highlight Configure and press the center (Select) button to
select it. A password entry page appears.
•Use the right (Exit) button to return to the main Normal Mode page.
Diagnostic Menu
• From the main Normal Mode page, press the Menu button to display the Main Menu
page.
•Use the left (Scroll) button to highlight Diagnostics and press the center (Select) button
to select it. A list of diagnostic readouts appears.
•Use the left and center buttons to scroll the screen up and down.
•Use the right (Exit) button to return to the main Normal Mode page.
Table 3. User parameters and button functions
Number Description Default value
P-01 Temperature units °C
P-02 Auto start NO
P-03 Display contrast 5
P-04 Beeper YES
P-05 Manual reset pre-alarm NO
NOTICE A password is required to display the Configure menu. These parameters are set
at the factory and cannot be changed by the user.
