INSIGHT Software
Operation
Thermo Scientific Evolution 200 Series User Guide 47
Related Topics
Setting Application Parameters
Scan
Measurement Tab for Scan
Correction Tab for Scan
Samples Tab for Scan
Accessories Tab for Scan
Measurement Tab for Scan
Related Topics
Setting Application Parameters
Scan
Estimated time Estimated duration of data acquisition. Increases as integration time
increases and as the data interval decreases. Varies inversely with scan
speed.
Autoscale Auto scale automatically adjusts the Y-axis scale for optimal viewing
of data during a measurement.
Ordinate Y scale To specify the Y-axis display limits, deselect Autoscale and set Max
and Min to the desired maximum and minimum Y values,
respectively, in the range 400 to -400.
Description
(optional)
Description of the template.
When setting up a Scan workbook, click Settings to
display the Measurement tab in the right pane.
Feature Description
Result Data analysis operation to perform automatically after sample measurement.
Select Off to not perform any operation.
The parameters for a selected operation appear to the right. See Finding Peaks in
Scan Data or Finding Value Level Crossings in Scan Data for information on
setting them and how results are displayed.
Feature Description
