INSIGHT Software
Operation
Thermo Scientific Evolution 200 Series User Guide 49
Select Standard reference correction with 0%R or 0%T baseline to display additional
features:
Related Topics
Setting Application Parameters
Scan
Instrument Tab for Scan
Measurement Tab for Scan
Samples Tab for Scan
Standard reference correction
with 0%R or 0%T baseline
Applies a 100%T baseline correction and a zero line
correction (0%R baseline) to a sample measured with a
reflectance accessory that is not absolute (for example, a
Diffuse Reflectance Accessory).
More:
The software multiplies the scan result at each data point by
the corresponding value in the table (explained below).
The calculation in reflectance performed in the instrument
is:
Requires a previously acquired 100%T baseline.
Correct single beam
substitution error
Allows the ratioed spectrum acquired with the single-beam
sphere to be corrected as if it were acquired with a
double-beam instrument (where the baseline is collected in
the integrating sphere). Requires that Data mode on the
Instrument tab be set to Absorbance, % Transmittance,
% Reflectance or Log(1/R).
Feature Description
Clear Table Clears information from the table.
Load Table Fills the table with wavelength and intensity values from a .tsv (tab separated
values) file or .csv (comma separated values) file containing X delimiter Y
pairs.
Save Table Saves in a .tsv file, .csv file, or .xml (extensible markup language) file the
wavelength and intensity values in the table.
Type Description
S - 0%R
100%T - 0%R
---------------------------------- S t d . R e f .×
