Image Output Terminal
Theory of Operation
Initial Issue
Transfix and Print Speeds
Configuration Card Parameters
Information stored on the configuration card includes the ethernet address, and personality
parameters. The system model configuration is determined by a combination of system hard-
ware capabilities. Feature value and ethernet address are configured at the factory, and are
“read only”. The feature value is fixed in the configuration card, and does not change. Ethernet
address is stored only on the configuration card, and cannot be rewritten. The ethernet
address is not written to the NVRAM chip.
Personality parameters are a subset of network configuration parameters, which are populated
to the configuration card over time as the system is configured by the customer. The personal-
ity parameters are copied, or “shadowed”, from the main board's NVRAM chip to the configura-
tion card during the normal operation of the system. When the configuration card is inserted
into a new system, the personality parameters on the configuration card are written into the
NVRAM chip of the new system. When a system is powered on, if it contains the configuration
card of another system, the personality parameters are automatically copied to the NVRAM
chip. If the configuration card is removed, the system reboots as a non-networking, non-
duplexing model.
Table 1 Transfix and Print Speeds
Characteristic Set Point, Paper Media (inches per second)
Fast Color Standard Enhanced Hi-Res/Photo
Peak transfix speed (Simplex) 20 ips 17 ips 13 ips 7 ips
Peak transfix speed (Duplex) 5 ips 5 ips 5 ips 5 ips
Peak Transfix Speed (Legal) 20 ips 17 ips 13 ips 7 ips
Peak transfix speed (Tray 1) 13 ips 7 ips 7 ips 7 ips
First Sheet Transfix Speed 7 ips 7 ips 7 ips 7 ips
Set Point, OHP Media
Peak Transfix Speed 5 ips
Table 2 Approximate Print Speeds
Tray (Source) / Resolution Simplex, A4 Paper Auto Duplex, A4 Paper
Tray 1
Fast Color (300 x 300 dpi) 10 pages per minute (ppm) 10 sides per minute (spm)
Standard (300 x 450 dpi) 9 ppm 9 spm
Enhanced (563 x 400 dpi) 8 ppm 4 spm
High Res/Photo (525 x 2400) 6 ppm 3 spm
PCL 600 x 300 Mode /
PCL 600 x 600 Mode
6.5 ppm / 3 ppm
Tray 2 ~ 4
Fast Color (300 x 300 dpi) 24 ppm 15 spm
Standard (300 x 450 dpi) 18 ppm 13 spm
Enhanced (563 x 400 dpi) 12 ppm 11 spm
High Res/Photo (525 x 2400) 7 ppm 7 spm
PCL 600 x 300 Mode /
PCL 600 x 600 Mode
13 ppm / 6 ppm
Table 3 Parameters Stored in the Configuration Card
NCL Subject NCL Item Size (bytes)
N/A “version” not
NCL parameter
version (of the layout of personality
parameters)
4
NEST Base Printer Name 48
NEST SysAdmin Contact 128 (truncated from 256)
NEST Printer Location 128 (truncated from 256)
NEST Asset Identifier 128 (truncated from 256)
IP Host Name 64
IP Domain Name 256
IP Network Mask 4
IP IP Address 4
IP Default Gateway 4
IP BOOTP/DHCP 1
IP DDNS 1
IP SMTP Server 256
IP IP Source 1
IP TCP/IP 1
IP AutoIP 1
IP DHCP Vendor Class ID 48
DNS Resolver Primary Name Server IP Address 4
DNS Resolver Secondary Name Server IP Address 4
DNS Resolver Multicast DNS 1
NBNS (WINS) Enable 1
NBNS (WINS) WINS Note Type 1
NBNS (WINS) Primary WINS Server 4
NBNS (WINS) Seconday WINS Server 4
Ethernet Speed 1
HTTP On 1
HTTP Information Forwarding 1
HTTP SMTP Server Automatic 1
HTTP Legal Settings 1
HTTP Admin_Password 11
HTTP Admin_Username 11
To Next Page
