April 2017
6-48
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
dC135, dC140
Launch Issue
General Procedures and Information
dC140 Analog Component Monitoring
Purpose
To provide tools to start (actuate) and stop (de-actuate) monitoring of specific analog components.
The nominal range of the analog value and, when monitoring is active, the current value is displayed.
The values are updated at least every second to allow the component state to be monitored.
Procedure
1. Enter Diagnostics, GP 1.
2. Touch dC140 Analog Component Monitoring.
3. Touch Chain-Link.
4. Enter the relevant Chain-Link number, refer to Table 1.
5. Touch OK.
6. Touch Start. The screen will display the information that follows:
• Chain-Link number of the component.
• Input or output code clarification.
• The enabled or disabled state.
• The output level.
7. To temporarily change the output level of a component:
a. Touch Level (wrench symbol).
b. Touch the +/- buttons to enter the new value (1 to 65535).
c. Touch OK.
8. Touch Stop All to stop component operation.
9. Touch Close to return to the Diagnostics screen.
10. Exit diagnostics, GP 1.
955-828 Feed Clutch On-Count 360K
955-830 Stamp Sol On Count 100K
955-831 Stamp Action Count 3K
956-802 Scan Count 6000K
956-803 Light Lamp Time 7200K
956-804 Lamp Turn On Count 6000K
Table 1 HFSI Details
Chain-Link Name Spec Life
Table 1 Component list
Chain-
Link
Component Name Description
010-200 Heat Roll NC Sensor: Inf The detected value of the mid heat roll sensor.
Range: 1019 (low) to 150 (high)
010-201 Heat Roll NC Sensor: Temp The compensated value of the mid heat roll sensor.
Range: 1019 (low) to 130 (high)
010-202 Heat Roll NC Sensor: Diff The differential value of the mid heat roll sensor.
Range: -32 (low) to 1024 (high)
010-203 Heat Roll STS The STS temperature value of the rear heat roll sen-
sor.
Range: 1018 (low) to 120 (high)
071-200 Tray 1 Size Sensor Analog Displays the value for tray 1 paper size.
Range: 0 to 989
072-200 Tray 2 Size Sensor Analog Displays the value for tray 2 paper size.
Range: 0 to 247
073-200 Tray 3 Size Sensor Analog Displays the value for tray 3 paper size.
Range: 0 to 247
074-200 Tray 4 Size Sensor Analog Displays the value for tray 4 paper size.
Range: 0 to 247
092-206 ATC_SNR_K TC detection in the developer housing assembly
To Next Page
