April 2017
2-476
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
074-210, 074-212
Launch Issue
Status Indicator RAPs
074-210 Tray 4 Lift Fail RAP
BSD-ON: BSD 7.12 Tray 4 Paper Stacking (3TM)
BSD-ON: BSD 7.21 Tray 4 Paper Stacking (TTM)
074-210 Tray 4 lift NG has occurred three consecutive times.
Initial Actions
• Check for obstructions behind the tray.
• Ensure that the tray is loaded correctly.
• Ensure the tray is pushed fully home.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedures that follow as necessary:
• GP 6 How to Check a Motor.
• GP 7 How to Check a Sensor.
Perform the steps that follow:
1. Enter dC330, code 074-102. Check the tray 3 level sensor, PL 80.20 Item 6.
2. Enter dC330, code 074-002. Check the tray 3 feed/lift up motor, PL 80.20 Item 4.
3. Enter dC330, code 042-003. Check the main motor,PL 40.10 Item 1.
4. Check the drive gears, PL 80.20 for wear or damage. Install new components as neces-
sary.
5. (3TM Only) Check the drive system between the bottom plate and the tray 4 feed/lift
motor for operation failure. Install new components as necessary, PL 70.20.
6. (TTM Only) Check the drive system between the bottom plate and the tray 4 feed/lift
motor for operation failure. Also check the bottom plate lift mechanism. Install new com
-
ponents as necessary, PL 70.67.
7. If the fault persists, install new components as necessary:
• 3TM PWB, PL 70.23 Item 5.
• TTM PWB, PL 70.90 Item 1.
074-212 Tray 4 Paper Size Sensor Fault RAP
BSD-ON: BSD 7.6 Tray 4 Paper Size Sensing (3TM)
BSD-ON: BSD 7.18 Tray 4 Paper Size Sensing (TTM)
074-212 Abnormal output AD value from tray 4 paper size sensor was detected.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Load the correct paper in tray 4.
2. Ensure that the customer is programming the job correctly.
3. Perform the relevant procedure:
• 3TM Checkout
• TTM Checkout
3TM Checkout
Perform the steps that follow:
1. Remove tray 4. Check underneath the tray for damage to the link mechanism. Also check
the actuator at the rear of tray 4. If necessary, install a new tray assembly, PL 70.10 Item
1.
2. Enter dC140 Analog Monitor, code 074-200. Check the tray 4 size sensor, PL 70.22 Item
9.
3. Check the wiring between the tray 4 size sensor and P/J549 on the 3TM PWB.
4. Reload the software, GP 4.
5. If the fault persists, install new components as necessary:
• Tray 4 size sensor, PL 70.22 Item 9.
•3TM PWB, PL 70.23 Item 5.
TTM Checkout
Perform the steps that follow:
1. Remove tray 4. Check the actuator at the rear of tray 4. If necessary, install a new tray
assembly, PL 70.67 Item 1.
2. Enter dC140 Analog Monitor, code 074-200. Check the tray 4 size sensor, PL 70.80 Item
1.
3. Check the wiring between the tray 4 size sensor and P/J549 on the TTM PWB.
4. Reload the software, GP 4.
5. If the fault persists, install new components as necessary:
• Tray 4 size sensor, PL 70.80 Item 1.
• TTM PWB, PL 70.90 Item 1.
