Page #61 background imageLoading...
Page #61 background image
April 2017
2-41
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
005-194, 005-196, 198, 199, 946, 948, 949, 950
Status Indicator RAPs
Launch Issue
005-194 Size Mismatch Jam on SS Mix-Size RAP
BSD-ON: BSD 5.3 DADF Document Size Sensing (2 of 2)
005-194 When ‘Slow Scan MIX’ is specified, it was detected that the size in the fast scan direc-
tion was different from that of the document guide width.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedure that follows as necessary:
• GP 7 How to Check a Sensor.
Perform the steps that follow:
1. Check the size of the document that was fed by the user.
2. Enter dC330. Check the sensors that follow:
• Code 005-215, tray APS sensor 1, PL 5.55 Item 6.
• Code 005-216, tray APS sensor 2, PL 5.55 Item 6.
• Code 005-217, tray APS sensor 3, PL 5.55 Item 6.
• Code 005-218, DADF APS sensor 1, PL 5.50 Item 8.
• Code 005-219, DADF APS sensor 2, PL 5.50 Item 8.
• Code 005-220, DADF APS sensor 3, PL 5.50 Item 8.
3. If the fault persists, install a new DADF PWB, PL 5.10 Item 11.
005-196, 198, 199, 946, 948, 949, 950 Size Mismatch Jam
RAP
BSD-ON: BSD 5.5 Document Feeding (2 of 2)
005-196 The 2nd sheet or later of the set was detected to be of a different size to the 1st sheet.
005-198 The length of the vertical scanning direction is less than the specified value, simplex
85mm (3.3 inches), duplex 110mm (4.3 inches).
005-199 The length of vertical scanning direction is the specified value or more, simplex
1275mm (50.1 inches), duplex 480.1mm (18.9 inches).
005-946 In no mix mode, a document with a shorter size in slow scan (SS) direction was fed.
005-948 In no mix mode, a document with a shorter size in slow scan (SS) direction was fed.
005-949 In no mix mode, a document with a longer size in slow scan (SS) direction was fed.
005-950 In no mix mode, a document with a longer size in slow scan (SS) direction was fed.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedure that follows as necessary:
• GP 7 How to Check a Sensor.
Perform the steps that follow:
1. Check the size of the document that was fed by the user.
2. Enter dC330. Check the sensors that follow:
• Code 005-206, DADF pre registration sensor, PL 5.70 Item 3.
• Code 005-221, tray size sensor 1, PL 5.55 Item 6.
• Code 005-222, tray size sensor 2, PL 5.55 Item 6.
3. If the fault persists, install a new DADF PWB, PL 5.10 Item 11.
