April 2017
2-70
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-259, 012-280, 012-283, 012-284
Launch Issue
Status Indicator RAPs
YN
Check the connections of P/J8706 and P/J8741. The connectors are good.
YN
Secure the connections.
Check for an open or short circuit between P/J8706 and P/J8741. The wiring is good.
YN
Repair the open wire or short circuit.
Measure the voltage between the finisher PWB P/J8706 pin 13 (+) and ground (-), and
between P/J8706 pin 15 (+) and ground (-).
Each voltage is approximately +24VDC.
YN
Check the +24VDC circuit. Refer to the Wiring Diagrams. If the fault persists, install
a new finisher PWB, PL 12.14 Item 1.
Install a new eject motor, PL 12.25 Item 15. If the fault persists, install a new finisher
PWB, PL 12.14 Item 1.
Check the wires and connectors for an intermittent open or short circuit. If the fault persists,
install a new finisher PWB, PL 12.14 Item 1.
012-283, 012-284 Set Clamp Home Sensor Fail Entry RAP
012-283 The set clamp home sensor failed to actuate within the specified time.
012-284 The set clamp home sensor failed to deactuate within the specified time.
Procedure
Go to the relevant procedure:
• Integrated office finisher installed, 012-283A, 012-284A Set Clamp Home Sensor Fail
RAP.
• Office finisher LX installed, 012-283B, 012-284B Set Clamp Home Sensor Fail RAP.
To Next Page
