Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
013-210, 013-211
Status Indicator RAPs
Launch Issue
013-210, 013-211 Booklet Staple Move Home Sensor Fail
RAP
BSD-ON: BSD 13.16 Office Finisher LX Booklet Staple Positioning
013-210 Booklet staple move home sensor does not actuate within designated time period.
013-211 Booklet staple move home sensor does not deactuate within designated time period.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Ensure the staple head is free from obstructions.
•Check dC122 Fault History for 013-306 or 013-307 faults. If either fault is listed, first per-
form the relevant procedure:
– 013-306 Booklet Safety Switches Open RAP.
– 013-307 Booklet Cover Open RAP.
Procedure
Enter dC330 code 013-143. Move the booklet staplers to actuate the booklet staple move
home sensor, PL 13.55 Item 13.
The display changes.
YN
Check the wiring between J8897 pin 2 and P/J8991 pin 2 for an open or short circuit, or
a loose or damaged connector.
The wiring is good.
YN
Reconnect or repair as necessary.
Measure the voltage between P/J8991 pins 3 and 1 on the booklet PWB. The voltage is
approximately +5VDC.
YN
Install a new booklet PWB, PL 13.70 Item 4.
Measure the voltage between P/J8991 pin 2 on the booklet PWB and ground. Move the
booklet staplers to actuate the booklet staple move home sensor.
The voltage changes.
YN
Install a new booklet staple move home sensor, PL 13.55 Item 13.
Install a new booklet PWB, PL 13.70 Item 4.
Enter dC330 code 013-028 and 013-029 alternately. The stapler move motor runs.
YN
Check the wiring between P/J8992 pins 1 to 6 on the booklet PWB and P/J8906 on the
booklet stapler move motor for an open or short circuit, or loose or damaged connectors.
The wiring is good.
YN
Reconnect or repair as necessary.
Monitor the voltage at J8984, pin 3. Enter dC330 code 013-028 and 013-029 alternately.
An AC clock pulse is detected.
YN
Check the wiring between J8984 pin 3 and J8985 pin 4. If the wiring is good, install
a new finisher PWB, PL 13.45 Item 2.
Install a new booklet stapler move motor, PL 13.55 Item 9. If the fault persists, install a
new booklet PWB, PL 13.70 Item 4.
Check the wiring for an intermittent fault.
A
A
B
B
To Next Page
