Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-224, 012-263, 012-224A, 012-263A
Launch Issue
Status Indicator RAPs
012-224, 012-263 Rear Tamper Home Sensor Fail Entry
RAP
012-224 The rear tamper home sensor failed to actuate within the specified time.
012-263 The rear tamper home sensor failed to deactuate within the specified time.
Procedure
Go to the relevant procedure:
• Integrated office finisher installed, 012-224A, 012-263A Rear Tamper Home Sensor Fail
RAP.
• Office finisher LX installed, 012-224B, 012-263B Rear Tamper Home Sensor Fail RAP.
012-224A, 012-263A Rear Tamper Home Sensor Fail RAP
BSD-ON: BSD 12.4 Integrated Office Finisher Tamping and Offset
Initial Actions
NOTE: Ensure the correct RAP is performed, refer to the 012-224, 012-263 Rear Tamper
Home Sensor Fail Entry RAP.
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Check the rear tamper home sensor, PL 12.25 Item 9 is correctly installed and has no for-
eign object and that the actuator is not broken.
• Switch off, then switch on the machine, GP 10.
Procedure
Check the rear tamper for any foreign object, deformation and binding that prevents it from
moving.
The rear tamper is good.
YN
Repair the deformation and remove the foreign object(s) and the binding. Install new com-
ponents as necessary, PL 12.26.
Check the drive mechanism to the rear tamper for a deformed or broken part and not-seated
gears.
The drive mechanism is good.
YN
Repair the rear tamper drive mechanism. Install new components as necessary, PL
12.26.
Enter dC330 code 012-221. Manually move the rear tamper to actuate the front tamper home
sensor.
The display of changes.
YN
Check the connections of P/J8700 and P/J8726. The connectors are good.
YN
Secure the connections.
Check for an open or short circuit between P/J8700 and P/J8726. The wiring is good.
YN
Repair the open wire or short circuit.
Measure the voltage between the finisher PWB P/J8700 pin 12 (+) and ground (-). The
voltage is approximately +5VDC.
YN
Check the +5VDC circuit. Refer to the Wiring Diagrams.
Measure the voltage between the finisher PWB P/J8700 pin 11 (+) and ground (-). Manu-
ally move the rear tamper to actuate the front tamper home sensor. The voltage
changes.
A
To Next Page
