April 2017
2-88
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-224B, 012-263B, 012-231
Launch Issue
Status Indicator RAPs
YN
Check the +24VDC circuit. Refer to the Wiring Diagrams. If the fault persists,
install a new finisher PWB, PL 13.45 Item 2.
Install a new finisher PWB, PL 13.45 Item 2.
Check the wiring between J8984 pins 13 to 17 on the finisher PWB, and the rear tamper
motor P/J8883 for an open or short circuit, or a loose or damaged connector.
The wir-
ing is good.
YN
Reconnect or repair as necessary.
Install a new rear tamper motor, PL 13.28 Item 8. If the fault persists, install a new finisher
PWB, PL 13.45 Item 2.
Install a new finisher PWB, PL 13.45 Item 2.
012-231 Punch Home Sensor Fail RAP
BSD-ON: BSD 13.6 Office Finisher LX Punch
012-231 The punch home sensor did not turn on within the specified time after the punch motor
started running.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Check the punch home actuator for deformation.
• Check the punch home sensor, PL 13.09 Item 5 for proper installation.
Procedure
Enter dC330 code 12-074 and 12-078 alternately to run the punch motor. The punch motor
runs.
YN
Check the wiring to the punch motor. Install new components as necessary:
• Punch motor, PL 13.09 Item 1.
• Finisher PWB, PL 13.45 Item 2.
Enter dC330 code 12-271. Use a piece of paper to actuate the punch home sensor. The dis-
play changes.
YN
Check the wiring to the punch motor. Install new components as necessary:
• Punch home sensor, PL 13.09 Item 5.
• Finisher PWB, PL 13.45 Item 2.
If the fault persists, install a new finisher PWB, PL 13.45 Item 2.
A B
To Next Page
