Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-221B, 012-223B, 012-224B, 012-263B
Status Indicator RAPs
Launch Issue
YN
Check the +24VDC circuit. Refer to the Wiring Diagrams. If the fault persists,
install a new finisher PWB, PL 13.45 Item 2.
Install a new finisher PWB, PL 13.45 Item 2.
Check the wiring between J8984 pins 18 to 22 on the finisher PWB and the front tamper
motor P/J8884 for an open or short circuit, or a loose or damaged connector.
The wir-
ing is good.
YN
Reconnect or repair as necessary.
Install a new front tamper motor, PL 13.28 Item 8. If the fault persists, install a new fin-
isher PWB, PL 13.45 Item 2.
Install a new finisher PWB, PL 13.45 Item 2.
012-224B, 012-263B Rear Tamper Home Sensor Fail RAP
BSD-ON: BSD 13.3 Office Finisher LX Interlock Switching
BSD-ON: BSD 13.9 Office Finisher LX Tamping and Offset (1 of 2)
BSD-ON: BSD 13.10 Office Finisher LX Tamping and Offset (2 of 2)
Procedure
NOTE: Ensure the correct RAP is performed, refer to the 012-224, 012-263 Rear Tamper
Home Sensor Fail Entry RAP.
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Manually operate the tamper mechanism. The tamper mechanism moves smoothly.
YN
Install a new components as necessary, PL 13.28.
Enter dC330 code 012-221. Manually operate the tamper mechanism to actuate the rear tam-
per home sensor. The display changes.
YN
Check the wiring between J8882 pin 2 and J8984 pin 8 for an open or short circuit, or a
loose or damaged connector.
The wiring is good.
YN
Reconnect or repair as necessary.
Measure the voltage between J8984 pins 9 and 7 on the finisher PWB. The voltage is
approximately +5VDC.
YN
Install a new finisher PWB, PL 13.45 Item 2.
Measure the voltage between J8984 pin 8 on the finisher PWB and ground. Manually
operate the tamper mechanism to actuate the rear tamper home sensor.
The voltage
changes.
YN
Install a new rear tamper home sensor, PL 13.28 Item 8.
Install a new finisher PWB, PL 13.45 Item 2.
Enter dC330 012-026 and 012-029. The rear tamper motor runs.
YN
Measure the voltage between J8984 pin 14 on the finisher PWB and ground. The volt-
age is approximately +24VDC.
YN
Measure the voltage between J8984 pin 4 on the finisher PWB and ground. The
voltage is approximately +24VDC.
A B
A B
To Next Page
