Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
075-135, 077-101, 077-900
Status Indicator RAPs
Launch Issue
075-135 Registration Sensor Jam (Bypass Tray) RAP
BSD-ON: BSD 8.1 Tray 1 and Bypass Tray Paper Transportation
BSD-ON: BSD 8.5 Registration
075-135 Paper does actuate the registration sensor in the specified time after the registration
clutch is energized when feeding from the bypass tray.
Initial Actions
• Check the condition of the paper in the bypass tray. Refer to GP 15 Paper and Media Size
Specifications
• Check that the paper guides are set correctly.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedures that follow as necessary:
• GP 7 How to Check a Sensor.
• GP 8 How to Check a Solenoid or Clutch.
Perform the steps that follow:
1. Check for obstructions in the paper path.
2. Check the bypass tray feed roll, bypass tray nudger roll and retard pad, PL 70.40 foreign
substances or wear. Clean or install new components as necessary.
3. Check the registration roll and takeaway roll 1, PL 80.55 for foreign substances or wear.
Clean or install new components as necessary.
4. Enter dC330, code 077-104. Check the registration sensor, PL 80.55 Item 4.
5. Enter dC330, code 077-002. Check the registration clutch, PL 80.55 Item 11.
6. Enter dC330, code 075-001. Check the bypass tray feed clutch, PL 70.40 Item 4.
7. Enter dC330, code 077-001. Check the take away clutch, PL 40.10 Item 5.
8. Check the drive assembly, PL 40.10 Item 7 for wear or damage.
9. If the fault persists, install new components as necessary:
•Drive PWB, PL 1.10 Item 3.
• ESS PWB, PL 3.10 Item 6.
077-101, 077-900 Registration Sensor Jam RAP
BSD-ON: BSD 8.5 Registration
077-101 The trail edge of the paper does not deactuate the registration sensor within the spec-
ified time after the registration clutch is energized.
077-900 The registration sensor detected remaining paper.
Initial Actions
• Check the condition of the paper in all trays. Refer to GP 15 Paper and Media Size Spec-
ifications
• Ensure that all the trays are loaded correctly.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedures that follow as necessary:
• GP 6 How to Check a Motor.
• GP 7 How to Check a Sensor.
Perform the steps that follow:
1. Check for obstructions in the paper path.
2. Check the registration roll and takeaway roll 1, PL 80.55 for foreign substances or wear.
Clean or install new components as necessary.
3. Enter dC330, code 077-104. Check the registration sensor, PL 80.55 Item 4.
4. Enter dC330, code 042-003. Check the main motor, PL 40.10 Item 1.
5. Enter dC330, code 077-002. Check the registration clutch, PL 80.55 Item 11.
6. Check the drive assembly, PL 40.10 Item 7 for wear or damage.
7. Check the registration transport assembly, PL 80.55 Item 1 for wear or damage.
8. If the fault persists, install new components as necessary:
• Drive PWB, PL 1.10 Item 3.
• ESS PWB, PL 3.10 Item 6.
To Next Page
