April 2017
2-73
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-291A, 012-301
Status Indicator RAPs
Launch Issue
Measure the voltage between the finisher PWB P/J8731 pin 5 (+) and ground (-). Enter
dC330 012-046 and 012-047 alternately.
The voltage changes.
YN
Install a new staple assembly, PL 12.11 Item 2.
Check the wires and connectors for an intermittent open or short circuit. If the fault per-
sists, install a new finisher PWB, PL 12.14 Item 1.
Check the wires and connectors for an intermittent open or short circuit. If the fault persists,
install a new finisher PWB, PL 12.14 Item 1.
012-301 Top Cover Interlock Open RAP
BSD-ON: BSD 12.1 Integrated Office Finisher DC Power and Interlock Switching
012-301 The top cover interlock open was detected.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Check that the top cover can be opened and closed.
• Check the finisher top cover interlock sensor and the finisher top cover interlock +24V
switch, PL 12.10 are correctly installed and undamaged.
• Switch off, then switch on the machine, GP 10.
Procedure
Enter dC330 code 012-300. Open, then close the top cover to actuate the finisher top cover
interlock sensor.
The display changes.
YN
Check the connections of P/J8701 and P/J8730. The connectors are good.
YN
Secure the connections.
Check for an open or short circuit between P/J8701 and P/J8730. The wiring is good.
YN
Repair the open or short circuit.
Measure the voltage between the finisher PWB P/J8701 pin 3 (+) and ground (-). The
voltage is approximately +5VDC.
YN
Check the +5VDC circuit. Refer to the Wiring Diagrams.
Measure the voltage between the finisher PWB P/J8701 pin 2 (+) and ground (-). Open,
then close the top cover to actuate the finisher top cover interlock sensor.
The voltage
changes.
YN
Install a new finisher top cover interlock sensor, PL 12.10 Item 20.
Check the wires and connectors for an intermittent open or short circuit. If the fault per-
sists, install a new finisher PWB, PL 12.14 Item 1.
Measure the voltage between the finisher PWB P/J8702 pin 1 (+) and ground (-). The volt-
age is approximately +24VDC.
YN
Check the +24VDC circuit. Refer to the Wiring Diagrams. If the fault persists, install a new
finisher PWB, PL 12.14 Item 1.
Check the wires and connectors for an intermittent open or short circuit. If the fault persists,
install a new finisher PWB, PL 12.14 Item 1.
A B
To Next Page
