April 2017
4-201
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
REP 80.22, REP 80.23
Repairs and Adjustments
Launch Issue
REP 80.22 HCF Feed, Nudger and Retard Rolls
Parts List on PL 80.61 and PL 80.62
Removal
NOTE: New feed, retard and nudger rolls must be installed at the same time.
WARNING
Switch off the electricity to the machine. Refer to GP 10. Disconnect the power cord
from the customer supply while performing tasks that do not need electricity. Electricity
can cause death or injury. Moving parts can cause injury.
1. Open the feeder top cover, PL 70.55.
2. Release the green lever to open the upper feeder assembly to reveal the three rolls.
NOTE: For reference purposes, the single roll in the upper feeder assembly is the nudger
roll. The double roll in the upper feeder assembly is the feed roll. The larger double roll in
the lower feeder component is the retard roll.
3. Remove each roll by squeezing the roll’s shaft at both ends and lifting the roll up and out
of the HCF.
Replacement
1. Install each new roll by squeezing its shaft at both ends and sliding the roll into place.
2. Check that the rolls turn freely.
3. Close the upper feeder assembly.
4. Close the feeder top cover of the HCF.
REP 80.23 HCF Feed Shaft Assembly
Parts List on PL 80.61
Removal
WARNING
Switch off the electricity to the machine. Refer to GP 10. Disconnect the power cord
from the customer supply while performing tasks that do not need electricity. Electricity
can cause death or injury. Moving parts can cause injury.
1. Remove the HCF feeder, REP 80.21.
2. Place the feeder on a flat surface.
3. Open the upper feeder assembly by releasing the green lever.
4. Remove the nudger roll by squeezing the roll’s shaft at both ends (with the thumb and
forefinger of one hand) and lifting the roll up and out of the HCF.
5. Remove the E-ring and bearing on the feed shaft (at the nudger roll end of the shaft).
6. Move the bearing at the opposite end of the shaft to the right, and slide the feed shaft to
the right to remove.
Replacement
The replacement is the reverse of the removal procedure.
