Xerox VersaLink B7035 Service Manual

April 2017
vi
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
Safety Information
Launch Issue
Introduction
Safety Information
The WARNING that follows is for general guidance when live working.
WARNING
Do not work in a confined space. 1m (39 inches) space is needed for safe working.
Safety Icons
The safety icons that follow are displayed on the machine:
ESD Caution Symbol
CAUTION
Certain components in this product are susceptible to damage from electrostatic discharge.
Observe all ESD procedures to avoid component damage.
Location Arrow Symbol
The location arrow symbol points to the location to install, to gain access to, or to release an
object.
Hot Surface Symbol
This symbol indicates hot surfaces. Take care when servicing the machine.
Lethal Voltage Symbol
This symbol indicates potentially lethal voltages. Take care when servicing the machine when
the power cord is connected.
Toner Cartridge
The product contains a toner cartridge that is recyclable. Under various state and local laws, it
may be illegal to dispose of the cartridge into the municipal waste. Check with the local waste
officials for details on recycling options or the proper disposal procedures.
Fuses
WARNING
Do not install a fuse of a different type or rating. Installing the wrong type or rating of
fuse can cause overheating and a risk of fire.
Part Replacement
Only use genuine Xerox approved spare parts or components to maintain compliance with leg-
islation and safety certification. Also refer to GP 21 Restriction of Hazardous Substances
(RoHS).
Disassembly Precautions
Do not leave the machine with any covers removed at a customer location.
Reassembly Precautions
Use extreme care during assembly. Check all harnesses to ensure they do not contact moving
parts and do not get trapped between components.
General Procedures
Observe all warnings displayed on the machine and written in the service procedures. Do not
attempt to perform any task that is not specified in the service procedures.

Xerox VersaLink B7035 Specifications

General

Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9.1 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	5.4 s
Scan to	E-mail, FTP, SMB, USB
Scanner type	-
Input color depth	24 bit
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Printing colors	Black
Maximum duty cycle	129000 pages per month
Page description languages	HP-GL, PCL 5e, PCL 6, TIFF, XPS
Internal memory	2048 MB
Processor cores	2
Processor frequency	1050 MHz
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Standard interfaces	Ethernet, NFC, USB 3.2 Gen 1 (3.1 Gen 1)
Optional connectivity	Wireless LAN
USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	1
Power consumption (average operating)	- W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Y
Linux operating systems supported	Fedora 24, openSUSE 13.2
Other operating systems supported	IBM AIX 7.2
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional x64, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Pro x64, Windows 8 x64
Sustainability certificates	ENERGY STAR
Total input capacity	- sheets
Paper tray media types	Bond paper, Card stock, Envelopes, Heavy paper, Labels, Letterhead, Plain paper, Pre-Printed, Recycled paper
ISO A-series sizes (A0...A9)	A3, A4
Maximum ISO A-series paper size	A3

Weight and Dimensions

Depth	670.8 mm
Width	590 mm
Height	767.9 mm
Weight	- g
