Status Indicator RAPs
045-310 Image Ready RAP
045-310 Controller image preparation failure detected.
Procedure
1. Switch off, then switch on the machine, GP 10.
2. Reload the software, GP 4.
045-311, 045-396 Controller Communication Fail RAP
BSD-ON: BSD 3.1 PWB Communications (ESS PWB to Drive PWB)
045-311 Communication failure between ESS PWB and DRIVE PWB was detected.
045-396 IO setup error of HASIC installed on drive PWB.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Check the connection between the ESS PWB ( P/J1334) and the drive PWB ( P/J401).
3. Install new components as necessary:
• ESS PWB, PL 3.10 Item 6.
• Drive PWB, PL 1.10 Item 3.
