Xerox VersaLink B7035 Service Manual

April 2017
2-94
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-295, 012-296, 012-300
Launch Issue
Status Indicator RAPs
Enter dC330 code 012-045 and 012-042 alternately. The stapler move motor runs.
YN
Check the wiring between P/J8981 pins 13 to 16 on the finisher PWB and P/J8888 on
the stapler move motor for an open or short circuit, or loose or damaged connectors.
The
wiring is good.
YN
Reconnect or repair as necessary.
Install a new staple move motor assembly, PL 13.20 Item 9. If the fault persists, install a
new finisher PWB, PL 13.45 Item 2.
Check for an intermittent connection. If the check is good, install a new stapler assembly, PL
13.20 Item 4. If the fault persists, install a new finisher PWB, PL 13.45 Item 2.
012-300 Eject Cover Open RAP
BSD-ON: BSD 13.3 Office Finisher LX Interlock Switching
012-300 Eject cover switch open was detected.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Ensure that the eject cover, PL 13.25 Item 1 is closed.
• Check the eject cover switch, PL 13.27 Item 19 for improper installation.
• Check eject cover switch connectors for connection failure.
• Check the switch actuator for damage.
Procedure
Enter dC330 code 012-300. Actuate the eject cover switch. The display changes
YN
Check the wiring between J8889 pin 1 and 2 for an open or short circuit, or loose or dam-
aged connectors. The wiring is good.
YN
Install a new eject cover switch, PL 13.27 Item 19.
Check the wiring between J8889 on the eject cover switch and J8982 on the finisher for
an open or short circuit, or loose or damaged connectors. If the check is good, install a
new finisher PWB, PL 13.45 Item 2.
The wiring is good.
YN
Reconnect or repair as necessary.
Install a new finisher PWB, PL 13.45 Item 2.
Install a new finisher PWB, PL 13.45 Item 2.
A

Xerox VersaLink B7035 Specifications

General

Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9.1 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	5.4 s
Scan to	E-mail, FTP, SMB, USB
Scanner type	-
Input color depth	24 bit
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Printing colors	Black
Maximum duty cycle	129000 pages per month
Page description languages	HP-GL, PCL 5e, PCL 6, TIFF, XPS
Internal memory	2048 MB
Processor cores	2
Processor frequency	1050 MHz
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Standard interfaces	Ethernet, NFC, USB 3.2 Gen 1 (3.1 Gen 1)
Optional connectivity	Wireless LAN
USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	1
Power consumption (average operating)	- W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Y
Linux operating systems supported	Fedora 24, openSUSE 13.2
Other operating systems supported	IBM AIX 7.2
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional x64, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Pro x64, Windows 8 x64
Sustainability certificates	ENERGY STAR
Total input capacity	- sheets
Paper tray media types	Bond paper, Card stock, Envelopes, Heavy paper, Labels, Letterhead, Plain paper, Pre-Printed, Recycled paper
ISO A-series sizes (A0...A9)	A3, A4
Maximum ISO A-series paper size	A3

Weight and Dimensions

Depth	670.8 mm
Width	590 mm
Height	767.9 mm
Weight	- g
