April 2017
2-472
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
073-101, 073-900, 073-105
Launch Issue
Status Indicator RAPs
• ESS PWB, PL 3.10 Item 6.
TTM Checkout
Perform the steps that follow:
1. Check the tray 3 takeaway roll, PL 80.65 Item 17 for foreign substances or wear. Clean or
install new components as necessary.
2. Enter dC330, code 072-103. Check the tray 2 feed out sensor, PL 80.65 Item 7.
3. Enter dC330, code 073-001. Check the tray 3 feed/lift motor, PL 80.20 Item 4.
4. Enter dC330, code 077-035. Check the take away motor 2, PL 70.85 Item 2.
5. Check the drive gears, PL 80.20 for wear or damage.
6. If the fault persists, install new components as necessary:
• TTM PWB, PL 70.90 Item 1.
• ESS PWB, PL 3.10 Item 6.
073-105 Registration Sensor Jam (Tray 3) RAP
BSD-ON: BSD 8.5 Registration
073-105 The registration sensor did not actuate within the specified time after the registration
clutch initialized during paper feed from tray 3.
Initial Actions
Check the condition of the paper in tray 3. Refer to GP 15 Paper and Media Size Specifications
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedures that follow as necessary:
• GP 6 How to Check a Motor.
• GP 7 How to Check a Sensor.
• GP 8 How to Check a Solenoid or Clutch.
Perform the steps that follow:
1. Check for obstructions in the paper path.
2. Check the tray 3 feed roll, nudger roll and retard roll, PL 80.25 for foreign substances or
wear. Clean or install new components as necessary.
3. Enter dC330, code 077-104. Check the registration sensor, PL 80.55 Item 4.
4. Enter dC330, code 077-002. Check the registration clutch, PL 80.55 Item 11.
5. Enter dC330, code 077-001. Check the take away clutch, PL 40.10 Item 5.
6. Enter dC330, code 077-033. As necessary, perform the steps that follow:
• Check the 3TM takeaway motor, PL 70.23 Item 4.
• Check the TTM takeaway motor 1, PL 70.85 Item 2.
7. Check the drive gears, PL 80.10 for wear or damage. Install new components as neces-
sary.
8. Check the drive assembly, PL 40.10 Item 7 for wear or damage.
9. If the fault persists, install new components as necessary:
•3TM PWB, PL 70.23 Item 5.
• TTM PWB, PL 70.90 Item 1.
• Drive PWB, PL 1.10 Item 3.
• ESS PWB, PL 3.10 Item 6.
To Next Page
