Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-161, 012-161A
Launch Issue
Status Indicator RAPs
012-161 Set Eject Jam Entry RAP
012-161 In the eject motor’s ejecting operation, eject home sensor on was detected within a
specified time after the start of the reverse operation of the eject motor.
Procedure
Go to the relevant procedure:
• Integrated office finisher installed, 012-161A Set Eject Jam RAP.
• Office finisher LX installed, 012-161B Set Eject Jam RAP.
012-161A Set Eject Jam RAP
BSD-ON: BSD 12.6 Integrated Office Finisher Set Eject (1 of 2)
Initial Actions
NOTE: Ensure the correct RAP is performed, refer to the 012-161 Set Eject Jam Entry RAP
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Check the eject home sensor, PL 12.26 Item 9 is correctly installed, not broken, and has
no foreign object.
• Switch off, then switch on the machine, GP 10.
Procedure
Check the specifications of paper, GP 15. Paper is in specification.
YN
Load paper that is in specification.
Check the condition of the paper. The paper is in normal condition without any problem
that causes the paper to be bent or caught.
YN
Resolve any problem that causes the paper to be bent or caught.
Check the eject mechanism, PL 12.25 for deformed parts, broken parts, and/or belt damage.
The eject mechanism is good.
YN
Repair the eject mechanism or install new components as necessary, PL 12.25.
Enter dC330 code 012-252. Use a piece of paper to actuate the eject home sensor. The dis-
play changes.
YN
Check the connections of P/J8700 and P/J8725. The connectors are good.
YN
Secure the connections.
Check for an open or short circuit between P/J8700 and P/J8725. The wiring is good.
YN
Repair the open or short circuit.
Measure the voltage between the finisher PWB P/J8700 pin 9 (+) and ground (-). The
voltage is approximately +5VDC.
YN
Check the +5VDC circuit. Refer to the Wiring Diagrams.
Measure the voltage between the finisher PWB P/J8700 pin 2 (+) and ground (-). Use a
piece of paper to actuate the eject home sensor.
The voltage changes.
A
To Next Page
