Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
078-301, 077-911
Status Indicator RAPs
Launch Issue
078-301 HCF Docking interlock Open RAP
BSD-ON: BSD 1.11 DC Power Distribution - HCF
078-301 HCF1 side out switch open. The HCF and the IOT were undocked.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Check that the HCF and the IOT are correctly docked.
• Switch off, then switch on the machine, GP 10.
Procedure
Refer to the procedure that follows as necessary:
• GP 9 How to Check a Switch.
Enter dC330 code 078-301. Dock then undock the HCF to actuate the HCF1 side out switch.
The display changes.
YN
Undock the HCF. Actuate the HCF1 side out switch, PL 70.60 Item 8. The display
changes.
YN
Measure the voltage between P/J8 pin 2 on the HCF PWB and ground. The volt-
age drops to less than +1VDC when the switch is actuated
YN
Check the wiring between:
• P/J8 pin 1 on the HCF PWB and FS003 on the HCF1 side out switch.
• P/J8 pin 2 on the HCF PWB and FS004 on the HCF1 side out switch.
If the wiring is good, install a new HCF1 side out switch, PL 70.60 Item 8.
Install a new HCF PWB, PL 70.60 Item 9.
Check the alignment of the HCF docking base and the IOT.
The fault may be intermittent. Check HCF1 side out switch wiring. If the fault persists, install
new components as necessary:
• HCF1 side out switch, PL 70.60 Item 8.
• HCF PWB, PL 70.60 Item 9.
077-911, 967, 968 Paper Mismatch RAP
077-911 Paper size mismatch user intervention.
077-967 The paper loaded is different from the specified paper type.
077-968 The paper loaded is different from the specified paper type.
Procedure
Switch off, then switch on the machine, GP 10. The fault persists.
YN
Perform SCP 5 Final Actions.
Load the specified paper, then rerun the job.
To Next Page
