April 2017
2-37
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
005-122, 005-123
Status Indicator RAPs
Launch Issue
005-122 DADF Simplex/Side 1 Pre Registration Sensor On
Jam RAP
BSD-ON: BSD 5.4 Document Feeding (1 of 2)
005-122 After pre-feed started for the first sheet (DADF feed motor on (CCW)) in simplex and
duplex, the DADF pre registration sensor did not turn on within the specified time.
After pre-feed started for the second sheet onwards (DADF feed motor on (CCW)) in duplex,
the DADF pre registration sensor did not turn on within the specified time.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedures that follow as necessary:
• GP 6 How to Check a Motor.
• GP 7 How to Check a Sensor.
• GP 8 How to Check a Solenoid or Clutch.
Perform the steps that follow:
1. Check for a foreign substance in the document path.
2. Check the surface of the feed roll and nudger roll for foreign substances or wear. Clean or
install new components as necessary, PL 5.25.
3. Enter dC330, code 005-206. Check the DADF pre registration sensor, PL 5.70 Item 3.
4. Enter dC330, code 005-062. Check the DADF feed clutch, PL 5.35 Item 2.
5. Enter dC330, code 005-004. Check the DADF feed motor, PL 5.30 Item 3.
6. Check the drive gears, PL 5.35 for wear or damage. Install new components as neces-
sary.
7. If the fault persists, install a new DADF PWB, PL 5.10 Item 11.
005-123 DADF Simplex/Side 1 Registration Sensor On Jam
RAP
BSD-ON: BSD 5.6 Document Scan, Invert and Exit Transportation
005-123 The DADF registration sensor does not turn on within the specified time after the
DADF pre registration sensor on.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedures that follow as necessary:
• GP 6 How to Check a Motor.
• GP 7 How to Check a Sensor.
• GP 8 How to Check a Solenoid or Clutch.
Perform the steps that follow:
1. Check for a foreign substance in the document path.
2. Check the surface of the takeaway roll and registration roll for foreign substances or wear.
Clean or install new components as necessary, PL 5.50.
3. Enter dC330, code 005-110. Check the DADF registration sensor, PL 5.70 Item 3.
4. Enter dC330, code 005-206. Check the DADF pre registration sensor, PL 5.70 Item 3.
5. Enter dC330, code 005-098. Check the DADF T/A clutch, PL 5.35 Item 2.
6. Enter dC330, code 005-008. Check the DADF feed motor, PL 5.30 Item 3.
7. Check the drive gears, PL 5.35 for wear or damage. Install new components as neces-
sary.
8. If the fault persists, install a new DADF PWB, PL 5.10 Item 11.
